Tonyscoots84's very long 60 gallon cube tank thread

[Tonyscoots84]

Just Ordered the black casings and fins for my 2 ai sol blues. What a great company and service...



[Tonyscoots84]

so im scratching the pipe hanging light fixture im just not crazy about the way it looks. im thinking about going with the sol standard fixture i just wonder if i could raise it a little higher then the legs it comes with instead of hanging it.



[Tonyscoots84]

just ordered the Ai Sol LED Light Mounting Rails. gonna try em out and see how they work. in the meantime i will try to design new much better higher feet.



[TimberTDI]

so im scratching the pipe hanging light fixture im just not crazy about the way it looks. im thinking about going with the sol standard fixture i just wonder if i could raise it a little higher then the legs it comes with instead of hanging it.

Did the bulkiness of using 1" EMT have anything to do with it? The mounting system you use should be discreet and as invisible as possible.



[Tonyscoots84]

It might have a little i just wasnt happy with the way it would of looked overall with the bends.

I agree 100% timber. I dont think the rails with the legs should be that bad. Im gonna have 2 on this tank if it was 1 then i would say it would prob. Be a problem. But i will find out when i get it.



[noelskii]

hope you actually get to set this tank up before you breakdown :redface:


Sent from my iPhone 5S using Reefs



[Tonyscoots84]

Lol Very funny noel... It will be up in june hopefully.



[Tonyscoots84]

Got these today :biggrin: i should be receiving my light mount on wednesday. I spoke to AI in regards to the legs on the mount and was told they are doing something about it and designing new legs which would raise the modules higher off the water line so thats great news. he had no ETA but he said near future so i will be intouch with him about this and will let you guys know.



[Tonyscoots84]

Thanks russ @ saltwatercritters.com :biggrin: fast shipping and great customer service as always



[duke62]

whats in the box in the middle..i cant read it



[Tonyscoots84]

Duke its a tds meter with temp



[Tonyscoots84]

hey guys need some help..... i need to install the flush kit and dual inline tds meter here is my rodi unit i checked out some videos but nothing with this unit :arg: thanks guys



[Tonyscoots84]

anyone?



[jedimaster1138]

I don't have that RO/DI (I have a BRS Plus) but in general...

The dual in-line TDS meter is meant to measure the TDS at 2 spots:

1) the output of the RO Resin - ie before the input of the DI stage
and
2) the output of your DI stage - ie the final product water. You want to put the meter close to the DI cannister so that you have lots of tubing dangling to run to your storage container.

I don't know if you have a DI stage so there's that. But that's the general jist of it. At least how mine is hooked up. I suppose they are all different.

The flush kit is slightly more complex to install...I just followed this video:
http://www.youtube.com/watch?v=mW7rYNyL2eY

but again, that's with the BRS unit, which is probably different than yours in detail, though not in principle...

Hope that at least sorta helps...and hope that someone with your exact unit can chime in with useful advice.



[jedimaster1138]

I see you got that unit from Russ at Saltwater Critters - I'm willing to bet he will have some solid advice on exactly how to hook that stuff up - Russ is the man x infinity.

:lol_large



[masterswimmer]

I see you got that unit from Russ at Saltwater Critters - I'm willing to bet he will have some solid advice on exactly how to hook that stuff up - Russ is the man x infinity.

:lol_large

:redface: Thanks for the kindness. I actually sent Tony a PM already.

Russ



[Tonyscoots84]

thanks jedi and russ...



[Tonyscoots84]

ok i think i got it... here is my beefed up aqua fx barracuda :yeah:

1st is the flush kit. took the flow restrictor out of the waste line existing the membrane and installed it where i have shown

2nd is the dual stage meter before sediment filter and after DI Resin



[masterswimmer]

Looks good to me T. Nice work.

R



[Tonyscoots84]

Jus got the led rail kit and black casings for the leds update coming tom.
